Model: Semi-Automatic Stencil Printer
Details
- Using precision guide rail and the import motor to drive the blade seat conversion, printing, and high accuracy.
- Printing scraper can rotate 45 degrees fixed up, easy printing stencil and squeegee cleaning and replacement.
- Block can be adjusted before and after the blade, to choose the right printing position.
- Combined with a fixed groove printing platen and PIN, easy installation and adjustment, for single, double sided printing.
- School Edition way to move a steel mesh, combined with printed (PCB), X, Y, Z. Convenient fine adjustment.
- Can be set to one-way and two-way, a variety of printing methods.
- With the automatic counting function to facilitate the production of output statistics.
- Adjustable blade angle, steel blade, rubber scrapers are suitable.
- Touch screen with a screen saver function, the time can be adjusted to protect the touch-screen life.
- Printing speed display can be adjusted.
|
Model
|
IE-S600
|
|
Dimensions
|
1000×670×1550mm
|
|
Platform size
|
320×600mm
|
|
PCB size
|
250×550mm
|
|
Template size
|
550×835mm
|
|
Printing speed
|
0-8000mm/min
|
|
PCB thickness
|
0-100mm
|
|
PCB fine tuning range
|
Front/side±10mm
|
|
Power supply
|
1PAC220V 50/60HZ
|
|
Platform height
|
850±20mm
|
|
Repeatability precision
|
±0.01mm
|
|
Positioning mode
|
outside/Reference hole
|
|
Weight
|
Approx.290Kg
|
